2014 - Mazda6 - Body and Accessories

DOOR LOCK SYSTEM OPERATION RECORD

Purpose

• Stores the record of the user's operation and the door lock system operation corresponding to the user's operation.

Function

• The door lock system operation record is stored by the rear body control module (RBCM) and displayed using the Mazda Modular Diagnostic System (M-MDS).

• The rear body control module (RBCM) stores the following when the front/rear door lock actuator operates.

• Time and date

• Part or function which output unlock signal

• Part or function which output lock signal

• Operated actuator

• Vehicle condition

Construction

• Based on the stored record, the rear body control module (RBCM) displays the following operation record on the M-MDS screen.



Operation

• Based on the lock/unlock signal, the rear body control module (RBCM) sends an operation signal to the front/rear door lock actuator motor, and stores the operation record at the same time.

  CAUTION:

  • Because it takes time from when the front/rear door lock actuator motor operates until lock/unlock is performed, the operation record may be stored before the lock/unlock switching is completed.

Fail-safe

• Function not equipped.
