1. Disconnect the negative battery cable. (See NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.5].)
2. Remove the following parts:a. A-pillar trim (RH) (See A-PILLAR TRIM REMOVAL/INSTALLATION.)b. Rear scuff plate (RH) (See REAR SCUFF PLATE REMOVAL/INSTALLATION.)c. Rear seat cushion (RH) (See REAR SEAT CUSHION REMOVAL/INSTALLATION.)d. Rear side seat back (RH) (See REAR SIDE SEAT BACK REMOVAL/INSTALLATION.)e. C-pillar trim (RH) (See C-PILLAR TRIM REMOVAL/INSTALLATION.)
3. Disconnect antenna feeder No.1.
4. Disconnect antenna amplifier.
5. Verify that the continuity between antenna feeder No.2 terminals is as indicated in the table.With audio system
With car-navigation system or SIRIUS satellite radio system
If not as indicated in the table, replace antenna feeder No.2.
With audio system
With car-navigation system or SIRIUS satellite radio system
